Prandtl-Meyer expansion fan


A Prandtl-Meyer expansion fan is a centered expansion process, which turns a supersonic flow around a convex corner. The fan consists of infinite number of Mach waves, diverging from a sharp corner. In case of a smooth corner, these waves can be extended backwards to meet at a point. Each wave in the expansion fan turns the flow gradually (in small steps). It is physically impossible to turn the flow away from itself through a single "shock" wave because it will violate the second law of thermodynamics.[1] Across the expansion fan, the flow accelerates (velocity increases) and the Mach number increases, while the static pressure, temperature and density decrease. Since the process is isentropic, the stagnation properties remain constant across the fan.


Flow properties

The expansion fan consists of infinite number of expansion waves or Mach lines.[2] The first Mach line is at an angle \mu_1 = arcsin \left( \frac{1}{M_1} \right) with respect to the flow direction and the last Mach line is at an angle \mu_2 = arcsin \left( \frac{1}{M_2} \right) with respect to final flow direction. Since the flow turns in small angles and the changes across each expansion wave are small, the whole process is isentropic.[1] This simplifies the calculations of the flow properties significantly. Since the flow is isentropic, the stagnation properties like stagnation pressure (p0), stagnation temperature (T0) and stagnation density (ρ0) remain constant. The final static properties are a function of the final flow Mach number (M2) and can be related to the initial flow conditions as follows,

\begin{array}{lcl} \frac{T_2}{T_1} &= & \bigg( \frac{1+\frac{\gamma -1}{2}M_1^2}{1+\frac{\gamma -1}{2}M_2^2} \bigg) \\ \frac{p_2}{p_1} &= & \bigg( \frac{1+\frac{\gamma -1}{2}M_1^2}{1+\frac{\gamma -1}{2}M_2^2} \bigg)^{\gamma/(\gamma-1)} \\ \frac{\rho_2}{\rho_1} &= &\bigg( \frac{1+\frac{\gamma -1}{2}M_1^2}{1+\frac{\gamma -1}{2}M_2^2} \bigg)^{1/(\gamma-1)} \end{array}

The Mach number after the turn (M2) is related to the initial Mach number (M1) and the turn angle (θ) by,

\theta = \nu(M_2) - \nu(M_1) \,

where, \nu(M) \, is the Prandtl-Meyer function. This function determines the angle through which a sonic flow (M = 1) must turn to reach a particular Mach number (M). Mathematically,

\begin{align} \nu(M)  & = \int \frac{\sqrt{M^2-1}}{1+\frac{\gamma -1}{2}M^2}\frac{\,dM}{M} \\ & = \sqrt{\frac{\gamma + 1}{\gamma -1}} \cdot arctan \sqrt{\frac{\gamma -1}{\gamma +1} (M^2 -1)} - arctan \sqrt{M^2 -1} \\ \end{align}

By convention, \nu(1) = 0. \, Thus, given the initial Mach number (M1), one can calculate \nu(M_1) \, and using the turn angle find \nu(M_2) \,. From the value of \nu(M_2) \, one can obtain the final Mach number (M2) and the other flow properties.

Maximum turn angle


As Mach number varies from 1 to \infty, \nu \, takes values from 0 to \nu_{max} \,, where

\nu_{max} = \frac{\pi}{2} \bigg( \sqrt{\frac{\gamma+1}{\gamma-1}} -1 \bigg)

This places a limit on how much a supersonic flow can turn through, with the maximum turn angle given by,

\theta_{max} = \nu_{max} - \nu(M_1) \,

One can also look at it as follows. A flow has to turn so that it can satisfy the boundary conditions. In an ideal flow, there are two kinds of boundary condition that the flow has to satisfy,

  1. Velocity boundary condition, which dictates that the component of the flow velocity normal to the wall be zero. It is also known as no-penetration boundary condition.
  2. Pressure boundary condition, which states that there cannot be a discontinuity in the static pressure inside the flow (since there are no shocks in the flow).

If the flow turns enough so that it becomes parallel to the wall, we do not need to worry about this boundary condition. However, as the flow turns, its static pressure decreases (as described earlier). If there is not enough pressure to start with, the flow won't be able to complete the turn and will not be parallel to the wall. This shows up as the maximum angle though which a flow can turn. Lower to Mach number to start with (i.e. small M1), greater the maximum angle though which the flow can turn.

The streamline which separates the final flow direction and the wall is known as a slipstream (shown as the dashed line in the figure). Across this line there is a jump in the temperature, density and tangential component of the velocity (normal component being zero). Beyond the slipstream the flow is stagnant (which automatically satisfies the velocity boundary condition at the wall). In case of real flow, a shear layer is observed instead of a slipstream, because of the additional no-slip boundary condition.


  1. ^ a b   Impossibility of expanding a flow through a single "shock" wave: Consider the scenario shown in the adjacent figure. As a supersonic flow turns, the normal component of the velocity increases (w2 > w1), while the tangential component remains constant (v2 = v1). The corresponding change is the entropy (Δs = s2s1) can be expressed as follows,
    \begin{align} \frac{\Delta s}{R}  & = ln \bigg[ \bigg( \frac{p_2}{p_1} \bigg)^{1/(\gamma-1)} \bigg( \frac{\rho_2}{\rho_1} \bigg)^{-\gamma/(\gamma-1)} \bigg] \\ & \approx \frac{\gamma+1}{12\gamma^2} \bigg( \frac{p_2 - p_1}{p_1} \bigg)^3 \\ & \approx \frac{\gamma+1}{12\gamma^2} \bigg[ \frac{\rho_1 w_1^2}{p_1} \bigg( 1-\frac{w_2}{w_1}\bigg) \bigg]^3 \end{align}
    where, R is the universal gas constant, γ is the ratio of specific heat capacities, ρ is the static density, p is the static pressure, s is the static entropy, and w is the component of flow velocity normal to the "shock". The suffix "1" and "2" refer to the initial and final conditions respectively. Since w2 > w1, this would mean that Δs < 0. Since this is not possible it means that it is impossible to turn a flow through a single shock wave. The argument may be further extended to show that such an expansion process can occur only if we consider a turn through infinite number of expansion waves in the limit \Delta s \rightarrow 0. Accordingly an expansion process is an isentropic process.
  2. ^   Mach lines (cone) and Mach angle: Mach lines is a concept usually encountered in 2-D supersonic flows (i.e. M \ge 1). They are a pair of bounding lines which separate the region of disturbed flow from the undisturbed part of the flow. These lines occur in pair and are oriented at an angle
    \textstyle \mu = arcsin \left( \frac{c}{u} \right) = arcsin \left( \frac{1}{M} \right)
    with respect to the direction of motion (also known as the Mach angle). In case of 3-D flow field these lines form a surface known as Mach cone, with Mach angle as the half angle of the cone. To understand the concept better, consider the case sketched in the figure. We know that when an object moves in a flow, it causes pressure disturbances (which travel at the speed of sound, also known as Mach waves). The figure shows an object moving from point A to B along the line AB at supersonic speeds (u > c). By the time the object reaches point B, the pressure disturbances from point A have traveled a distance c·t and are now at circumference of the circle (with center at point A). There are infinite such circles with their center on the line AB, each representing the location of the disturbances due to the motion of the object. The lines propagating outwards from point B and tangent to all these circles are known as Mach lines. Note: These concepts have a physical meaning only for supersonic flows (u \ge c). In case of subsonic flows the disturbances will travel faster than the source and the argument of the arcsin() function will be greater than one.

See also


  • Liepmann, Hans W.; Roshko, A. [1957] (2001). Elements of Gasdynamics. Dover Publications. ISBN 0-486-41963-0.
  • Anderson, John D. Jr. [1984] (January 2001). Fundamentals of Aerodynamics, 3rd Edition, McGraw-Hill Science/Engineering/Math. ISBN 0-07-237335-0.
  • Shapiro, Ascher H. [1953]. The Dynamics and Thermodynamics of Compressible Fluid Flow, Volume 1. Ronald Press. ISBN 978-0-471-06691-0.
