Piston pumps and wobble piston pumps form the backbone of modern liquid chromatography (LC) and pharmaceutical production processes. These high-precision dosing pumps excel through maintenance-free continuous operation and exceptional chemical resistance thanks to corrosion-resistant corundum pistons in equivalent cylinders.

The valveless FMI wobble piston pumps operate with ground-in, abrasion-resistant corundum pistons and achieve flow rates from 10 to 150 ml/min at maximum 9.6 bar operating pressure. All media-contacting components consist of inert fluoroplastics such as polytetrafluoroethylene (PTFE) and polyvinylidene fluoride (PVDF), enabling safe pumping of aggressive media, slurries, suspensions and emulsions with viscosities up to 500 cP.

For applications with minimal flow rates, micro double-piston pumps offer exceptional precision: flow rates of 200-750 ml/h at pressures up to 50 bar are achieved with 0.1% reproducibility and 0.15% flow accuracy. The microprocessor-controlled stepper motor ensures extremely linear, pressure-independent media flows and enables remote control via 24V or RS232 interfaces.

All piston pumps meet FDA and BfR conformity as well as the European Pharmacopoeia, making them recognized pharmaceutical pumps in medical, semiconductor and biotechnology applications. The RoHS-compliant design guarantees environmentally responsible production.

Product range includes:

• Low-pressure transfer pump for critical media with low-voltage drive
• Precision micro pump head
• RCT® accessories: Micrometer set
• RCT® accessories: Transition thread adapter
• RCT® accessories: Transition adapter for rigid tubing
• RCT® accessories: Transition adapter for flexible tubing
• Wobble piston dosing pump
• Wobble piston micro dosing pump E-1500-MP

Piston pumps and other products, such as diaphragm pumps, centrifugal pumps and gear pumps, are available directly in the online shop of RCT Reichelt Chemietechnik. The range of RCT Reichelt Chemietechnik offers over 80,000 different products, which are used among others in mechanical engineering, chemical technology, process engineering as well as medical technology.
