Ultrasonic flow meters:

ES-FLOW

Ultrasonic Flow Meter for Very Small Flow Rates

Bronkhorst High-Tech B.V.

Switch fluids without conversion or recalibration

Suitable for hygienic applications

Compact dosing solutions available

Ultrasonic flow meter ES-FLOW ES-103I
Ultrasonic flow meter ES-FLOW ES-113C
Ultrasonic flow meter with dosing pump
Ultrasonic flow meter ES-FLOW ES-103I
Ultrasonic flow meter ES-FLOW ES-113C
Ultrasonic flow meter with dosing pump

Independent of Liquid Properties

The Bronkhorst® ES-FLOW is designed to measure tiny volume flows (from 2 to 1500 ml/min based on H2O) using ultrasound in a small bore tube. A wide range of clear liquids can be measured independent of fluid density, temperature and viscosity.Due to the combination of a straight sensor tube with zero dead volume, self-drainability, orbital TIG-welding and hygienic connections, this flow meter can be used for hygienic applications. Wetted parts are made of stainless steel, except for the rubber gaskets at the Triclamp or flange connections. The exterior design is according to IP67. For non-hygienic applications, the instruments can also be equipped with compression type fittings.

The optional user interface is a capacitive touchscreen with a TFT display to operate and readout the instrument. The on-board PID controller can be used to drive a control valve or pump for precise batch or continuous dosing of samples or additives.

Ultrasonic flow meter ES-FLOW ES-103I

1

Ultrasonic flow meter ES-FLOW ES-103I

Ultrasonic flow meter ES-FLOW ES-113C

2

Ultrasonic flow meter ES-FLOW ES-113C

Ultrasonic flow meter with dosing pump

3

Ultrasonic flow meter with dosing pump

Product classification ES-FLOW

Applications

Product categories

Target Industries

Beverages
Biotechnology
Chemistry
Food
Pharma
Plastics
