Glass fabric films provide a reliable solution for demanding insulation tasks in industrial applications. These asbestos-free semi-finished products combine the mechanical strength of glass fiber fabric with the specific properties of various surface coatings.

Material Diversity for Different Requirements

The product range includes various coating variants, each offering optimal properties for specific application areas. PTFE-coated (polytetrafluoroethylene) glass fabric films are characterized by excellent electrical insulation properties and chemical resistance. These properties make them particularly suitable for applications in the pharmaceutical, food, and beverage industries.

Silicone-coated variants offer extreme flexibility in the diagonal direction and work reliably in a temperature range from -60°C to +200°C. The low water absorption of maximum 3.8% after 24 hours as well as the firm bond between glass fabric and silicone coating ensure long-term functional reliability.

Aluminum-coated glass fabric films utilize the reflective properties of the metal for thermal insulation and additionally provide a protective shield function against external influences.

Technical Performance Features

The asbestos-free glass fabrics achieve extraordinary heat stability with operating temperatures up to 550°C while maintaining high mechanical strength. The chemical resistance to organic acids and vapors significantly expands the application spectrum.

Application Areas

Glass fabric films are used in transformer construction, engine construction, laboratory technology, chemical technology, electrical engineering, and general mechanical engineering. The available designs include:

• Glass fiber fabric - asbestos-free
• Glass fabric film - aluminum-coated
• Glass fabric film - PTFE-coated
• Glass fabric film - PTFE-coated, one-sided self-adhesive
• Glass fabric film - PTFE-coated, one-sided self-adhesive, section
• Glass fabric film - silicone-coated

Glass fabric films and other products, such as adhesive tapes and tapes made from glass fabric or ceramic, are available directly in the online shop of RCT Reichelt Chemietechnik. The range of RCT Reichelt Chemietechnik offers over 80,000 different products, which are used among others in mechanical engineering, chemical technology, process engineering as well as medical technology.
