Diaphragm Valves for Aggressive Media in Chemical, Pharmaceutical and Laboratory Technology
RCT Reichelt Chemietechnik GmbH + Co.
Diaphragm valves are indispensable components in chemical technology, pharmaceutical technology and laboratory technology for the safe handling of aggressive media and gases. These robust fittings are characterized by their high chemical resistance and reliable sealing.
Material diversity for every application area
The available materials cover a wide range of requirements: Polyvinyl chloride (PVC-U) offers excellent chemical resistance at temperatures from -10°C to +60°C. Polypropylene (PP) enables operating temperatures up to +80°C at maximum operating pressures of 10 bar. Polyvinylidene fluoride (PVDF) represents the premium solution for critical media and allows working temperatures up to +120°C.
Manual and pneumatic control
Manually controlled diaphragm valves are available in nominal sizes DN 15 to DN 50 and offer flexible connection options via solvent socket ends, threaded connections or GRP flanges. Pneumatically controlled variants enable automated process control with control functions such as spring-return closing (NC), spring-return opening (NO) or double-acting (DA).
Product range includes:
• Diaphragm valve made from PP
• Diaphragm valve made from PP - pneumatically controlled
• Diaphragm valve made from PP or PVDF - pneumatically controlled
• Diaphragm valve made from PVC-U
• Diaphragm valve made from PVC-U - pneumatically controlled
• Diaphragm valve made from PVDF
• Diaphragm valve made from PVDF - pneumatically controlled
The diaphragm materials EPDM and PTFE ensure optimal sealing with different media and temperature ranges. Pneumatic variants operate with control pressures up to 7 bar and operating pressures up to 6 bar.
Diaphragm valves and other products, such as solenoid valves, check valves and control valves, are available directly in the online shop of RCT Reichelt Chemietechnik. The range of RCT Reichelt Chemietechnik offers over 80,000 different products, which are used among others in mechanical engineering, chemical technology, process engineering as well as medical technology.
